Multi-Terminal Battery Module Busbar
Insulated laminated busbar with eight double-threaded terminals for high-current distribution across EV battery modules.
Description
Insulated laminated busbar with eight double-threaded terminals for high-current distribution across EV battery modules.
A multi-terminal battery module busbar distributes high current across the parallel cell groups of an EV battery module. This laminate carries eight double-terminal positions on a single insulated plate, replacing the bundle of cables or flat straps typically used for module-level interconnection.
Specifications
| Parameter | Value |
|---|---|
| Conductor | C11000 copper, tin plated |
| Conductor layers | 2 (typical) |
| Dielectric | PET / Nomex / epoxy (DLF), selected by voltage class |
| Terminals | 8 × double M6 threaded studs (position per drawing) |
| Current rating | Per design, up to ~1000 A |
| Edge treatment | Full edge sealing |
| SKU | SY-BB-101 |
Typical Applications
- EV battery modules (BEV / PHEV)
- ESS module interconnection
- High-current distribution boards
Design Notes
Terminal count, position and stud size are set by your drawing. Fused link positions can be integrated into the same laminate.
All specifications are typical and fully customizable to your drawing. Request a quote for this busbar or send your own specification — our engineers respond within one business day.
